System type: 1 unit reverse phase;
Rated power:700W
Maximum power: 1400W
Peak power: 2800W
Nominal sensitivity (1w@1m): 104db
Nominal Impedance: 8 OHMS
Recommended amplifier rated output power : 1000W @8 OHMS
Maximum sound Pressure level: 135dB@1400w(138dB@2800W)
System type: 1 unit reverse phase;
Rated power:700W
Maximum power: 1400W
Peak power: 2800W
Nominal sensitivity (1w@1m): 104db
Nominal Impedance: 8 OHMS
Recommended amplifier rated output power : 1000W @8 OHMS
Maximum sound Pressure level: 135dB@1400w(138dB@2800W)
Frequency Bandwidth:35Hz—300Hz
Transducer configuration: low frequency driver 18″ 460mm unit with 100mm voice coil × 220Magnetic Steel *1 Frequency division mode: Passive
Connector : Speakon NL4x2pin 1+/2+POS PIN1-/2-NEG
Box material: 18mm ( 0.7″ ) MDF Medium density fiber board
Box size: W 600mm* D 700mm *H 531mm NET Weight: 48kg
